MS39747TEA
phone 189 2646 8515
Three-Phase Sensorless Motor Driver IC
Brand: RM Semiconductor
Operating Voltage: 4-38V, Typical Voltage 24V
Continuous Current: 2A, Peak Current Up to 3A
Key Features:
Quiet Operation
Sensorless Sinusoidal Wave Startup
Low Rdson MOSFET (High-Side + Low-Side: 360mΩ)
Rich Speed Curves Configurable via EEPROM
Multiple Startup Modes & Adjustable Startup Parameters
Low Power Consumption Mode
Comprehensive Protection Functions:
Overvoltage, Overcurrent, Overtemperature Protection
Undervoltage Lockout (UVLO)
Lock Detection: Configurable Restart Times After Stall
Applications: Household Fans, Automotive Fans, Automotive Seat Fans
Consult Now Download Sheet
